A/D Conversion
|
24-bit 128 times
oversampling delta-sigma Modulation |
D/A Conversion
|
24-bit 128 times
oversampling delta-sigma Modulation |
Sampling
Frequency
|
SRV-3030: 44.1 kHz,
SRV-3030D: 44.1 kHz, 48 kHz |
Program Memory
|
Preset: 100, User: 100,
SmartMediaª Card: 10 banks x 100 |
Frequency
Response
|
Direct: 5 Hz to 200
kHz; -3/+1 dB, Effected: 15 Hz to 20 kHz; -3/+1 dB
|
Nominal Input
Level
|
-20 to +4 dBm
|
Input Impedance
|
20 kohm (HOT-COLD), 12
kohm (HOT-GND, COLD-GND) |
Nominal Output
Level
|
-20 to +4 dBm
|
Output Impedance
|
640ohm (HOT-COLD),
320ohm (HOT-GND, COLD-GND) |
Harmonic
Distortion
|
Direct: 0.01 % or less,
Effected: 0.02 % or less |
Dynamic Range
|
Direct: 110 dB or
greater, Effected: 100 dB or greater |
Controls
|
Knobs: Reverb
Level/Param1, Reverb Time/Param2, Assignable/Param3,
Number/Page/Push Enter, Buttons: Bank, Category, Preview, EZ
Edit, Custom, Unit A/B, Bypass, Memory, System
|
Display
|
Custom backlit graphic
LCD |
Connectors
|
MIDI (In, Thru/Out),
XLR Balanced Outputs (A, B), XLR Balanced Inputs (A,B), TRS
1/4" Outputs (A,B), TRS 1/4" Inputs (A,B), Expression Pedal,
Footswitch, [SRV-3030D only: Digital Output, Digital Input
(coaxial)], AC in *XLR 1: GND, 2: HOT, 3: COLD; TRS T: HOT,
R: COLD, S: GND |
Power Supply
|
AC117V/230V/240V
|
Power
Consumption
|
20W |
Dimensions
|
SRV-3030: 482 (W) x 204
(D) x 44 (H) mm, SRV-3030D: 482 (W) x 205 (D) x 44 (H) mm
(19" x 8-1/16" x 1-3/4") --- EIA-1U rackmount size
|
Weight
|
2.8 kg (6 lbs. 3 oz.)
|
Options
|
SmartMedia(tm) Card
S2M-5, S4M-5, Footswitches DP-2, BOSS FS-5U/5L, Expression
Pedal EV-5, EV-300L + PCS-33 |
|
